Acoustic Testing Pro Digital Sound Level Analyzer
This Acoustic Testing Pro Digital Sound Level Analyzer has solution analyze degree 0.1 dB, test frequency range 31.5 Hz to 8000 Hz, operating humidity < 80 % RH.
Technical Specifications
| Show device | 0.7 in (18 mm) LCD, 3 1/2 digits |
| Test range | 30 dB to 70 dB 60 dB to 100 dB 90 dB to 130 dB |
| Solution analyze degree | 0.1 dB |
| Test frequency range | 31.5 Hz to 8000 Hz |
| Microphone types | Electric condenser microphone. |
| Microphone size | 0.5 in (12.7 mm) standard size. |
| Range selection | 30 dB to 70 dB, 60 dB to 100 dB, 90 dB to 130 dB, 40 dB on each step, with over & under range indicating Fast t= 200 ms Slow t = 500 ms, |
| Use the power | DC 9 V battery x2 PCs or equivalent, heavy duty or alkaline type. |
| Current consumption | Approximately DC 17 mA |
| Operating ambient temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Operating humidity | < 80 % RH |
| Dimensions | 10.2 in x 3.42 in x 1.41 in (260 mm × 87 mm × 36 mm) |
| Weight amount | 15.87 oz (450 g) |
