Acoustic Testing Pro Ultrasonic Thickness Gauge
Acoustic Testing Pro ultrasonic thickness gauge measures the wall thickness of metallic (cast iron, steel and aluminum) and non-metallic (ceramics, plastics and glass) substrates and any other ultrasonic wave-conductor using ultrasonic technology.
Overview
Acoustic Testing Pro ultrasonic thickness gauge measures the wall thickness of metallic (cast iron, steel and aluminum) and non-metallic (ceramics, plastics and glass) substrates and any other ultrasonic wave-conductor using ultrasonic technology. Its ideal for measuring the effects of corrosion or erosion on tanks, pipes, or any structure where access is limited to one side.
Features
- Excellent Timer chips provide fast, accurate readings
- Ultrasonic double crystal probe
- Automatic Gain switchable
- Two measurement modes: QC Mode/Statistics Mode
- Built-in sound velocity of multiple materials
- Sound velocity can be measured according to thickness
- Large measuring range of thickness
Technical Specifications
| Measuring Range | 0.031 in to 23.62 in (0.8 mm to 600 mm) |
| Resolution | 0.031 in to 0.393701 in (0.8 mm to 10 mm): 3.937008e-5 in (0.001 mm) 0.39 in to 3.94 in (10 mm to 100 mm): 0.0003937008 in (0.01 mm) 3.94 to 23.62 in (100 mm to 600 mm): 0.00393701 in (0.1 mm) |
| Accuracy | 0.0314961 in to 0.393701 in (0.8 mm to 10 mm):± 0.001968504 in (0.05 mm) 0.393701 in to 23.622 in (10 mm to 600 mm):±0.5% reading |
| Probe | 5 MHz φ10 double-crystal probe |
| Display | 240 x 160 dot matrix LCD |
| Unit | mm/inch |
| Power Supply | 2 pcs of 1.5 V AAA alkaline battery |
| Weight | About 0.507063 lbs (230 g) |
| Operation Temperature Range | 50 °F to 122 °F (-10 ℃ to 50 ℃)，0 to 85% RH（No condensation） |
| Storage Temperature Range | 14 °F to 140 °F (-10 ℃ to 60 ℃)，0 to 85% RH（No condensation） |
| Weight | 0.72 lb (330 g) |
