Acoustic Testing Pro Ultrasonic Liquid Level Indicator
Acoustic Testing Pro Ultrasonic Liquid Level Indicator is designed to measure the presence or absence of liquid at a certain height position in a container or in pipelines.
Overview
Acoustic Testing Pro Ultrasonic Liquid Level Indicator is designed to measure the presence or absence of liquid at a certain height position in a container or in pipelines. Due to the technique of non-contact detection, the liquid level indicator is the ideal choice for detection of dangerous toxic or corrosive liquids.
Features
• No contact with medium
• Suitable for toxic, corrosive, or invasive medium
• No need for drilling or welding
• Advanced ultrasonic sensor technology
• Reliable measurement results
• Easy and convenient to operate and maintain
• Ultrasonic adaptive detection algorithm
• High-contrast OLED color display
• Good user interface design
• Comprehensive software displays
• Bilingual operation modes (Chinese/English)
Technical Specifications
| Measurement Accuracy | < 0.07 in (< 2 mm) |
| Tank Wall Thickness | 0.11 in to 1.18 in (3 mm to 30 mm) |
| Measurable Tank Material | Steel, stainless steel, glass, unformed plastics |
| Measurable Medium | Pure liquid, milky liquid, suspension liquid |
| Ambient Humidity | 15 % to 85 % RH |
| Power Supply | Two 18650 lithium batteries |
| Current | 150 mAh (on average) |
| Ambient Temperature | -4 ℉ to 140 ℉ (-20 ℃ to 60 ℃) |
