Acoustic Testing Pro Integrated Crack Detector
Acoustic Testing Pro Integrated Crack Detector can quickly, non-destructively and accurately detect various defects (cracks, inclusions, blowhole, etc.) inside the workpiece.
Overview
Acoustic Testing Pro Integrated Crack Detector can quickly, non-destructively and accurately detect various defects (cracks, inclusions, blowhole, etc.) inside the workpiece. The product is unique in design, easy to operate and durable. It adopts all-Chinese true color liquid crystal display. Different color schemes can be selected according to the environment.
Technical Specifications
| Working Frequency | 0.2 MHz to 20 MHz |
| Pulse Width | Square wave width 30~1000ns adjustable, step 0.1ns |
| Detection Range | 0 in to 551.18 in (0 mm to 14000 mm) (Steel longitudinal wave) |
| Pulse Shift | -1.77 in x 39.37 in (-45 mm to 1000 mm (steel longitudinal wave) |
| Material Sound Velocity | 300 m/s to 15000 m/s |
| Detection Method | Negative wave, positive wave, two-way wave, filter, RF wave |
| Gain Adjustment | 0 dB to 110 dB: 0.1/1/2/6 step adjustment |
