Acoustic Testing Pro Flaw Crack Detector
Acoustic Testing Pro flaw crack detector is widely used in oil field, boat making, car making, coalmine, machine, medicine, airplane making and internal combustion engine parts, and fit to the detecting for the surface defecting caused by Forge, Quenching, Welding, Fatigue etc.
Overview
Acoustic Testing Pro flaw crack detector is widely used in oil field, boat making, car making, coalmine, machine, medicine, airplane making and internal combustion engine parts, and fit to the detecting for the surface defecting caused by Forge, Quenching, Welding, Fatigue etc.
Technical Specifications
| Power Supply | Alternating Current |
| Input Voltage | AC 220 V, 50 Hz |
| Working Powder | AC 2.2 A |
| Work Period | 5 seconds on to -5 seconds off |
| Temperature | 14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Magnetization Pole Distance | 0 in to 9.02 in (0 mm to 200 mm) |
| Overall Dimension | 5.51 in x 9.06 in x 1.77 in (140 mm x 230 mm x 45 mm) |
| Net Weight | 5.29 Ib (2.4 kg) |
| Lift Weight | 13.23 Ib > (6 kg) |
