Acoustic Testing Pro Digital Metal Ultrasonic Thickness Gauge
Acoustic Testing Pro digital metal ultrasonic thickness gauge measuring with ultrasonic waves is applicable for measuring the thickness of any material in which an ultrasonic wave can be transmitted and reflected from the other face.
Overview
Acoustic Testing Pro digital metal ultrasonic thickness gauge measuring with ultrasonic waves is applicable for measuring the thickness of any material in which an ultrasonic wave can be transmitted and reflected from the other face. The gauge can provide quick and accurate measurement to various work pieces such as sheets of board and processing parts. Another important application of the gauge is to monitor various pipes and pressure vessels in production equipment and monitor the thinning degree during using. It can be widely used in petroleum, chemical, metallurgy, shipping, aerospace, aviation and other fields.
Technical Specifications
| Display | 128 × 64 LCD with LED Backlight, Colour Display |
| Measuring Range | 0.029 in to 23.62 in (Steel） (0.75 mm to 600 mm) |
| Velocity Range | 3280.84 ft/s to 32781.61 ft/s (1000 m/s to 9999 m/s) |
| Resolution | 0.000039 in (0.001 mm) |
| Measuring Accuracy | 0.0015 in（ ± 0.5% H + 0.04 mm); H is thickness value |
| Measurement Cycle | Single point measurement 6 times/per |
| Storage | 3000 values of saved data |
| Power Source | 2 pcs 1.5 V AAA size |
| USB Port | YES |
| Working Time | More than 50 hours (LED backlight off) |
| Dimensions | 5.70 in × 2.87 in × 1.25 in (145 mm × 73 mm × 32 mm) |
| Weight | 0.54 lb (245 g) |
