Acoustic Testing Pro Automatic Probes Coating Thickness Gauge
Features
- Versatile Calibration Options
- Recission Display Resolution
- Extensive Statistics and Storage
- Flexible Working Methods
- Two Measurement Modes
- Dual Shutdown Options
- Customizable Alarm and Bound
- Error Handling and Deletion
- Comprehensive Printing Features
Technical Specifications
| Measuring Range | 0 µm to 1250 µm with standard probe |
| Probes Available | 5 probes for F (ferrous: on steel or iron) and N (non-ferrous metals) |
| Tolerance | F1: ±(1μ+3%H), N1 ± (1.5μ+3% H) |
| Resolution | Alphanumeric with 4 large digits |
| Standards | DIN, ISO, ASTM, BS |
| Min. Measuring Area | F1:(standard probe) |
| Min. Curvature Radius | Convex:3, Concave:50 |
| Min. Substrate Thickness | Type F: 0.5 |
| Calibration | One point, Two-point, Basic calibration |
| Statistics | Maximum and minimum of 3000 readings |
| Data Memory | 500 measuring data |
| Limits | Adjustable with acoustic alarm |
| Interface | USB 2.0 |
| Operating Temperature | 32 °F to 104 °F (0 ℃ to 40 ℃) |
| Power Supply | AA size 1.5 V |
| Dimensions | 4.92 in x 2.64 in x 1.23 in (125 mm x 67 mm x 31 mm) |
| Weight | 0.764 lb (345 g) |
