Name: Thickness Tester with PC Communication (Error Function) - Acoustic Testing Pro
SKU: ACTPYR00ZK

Key Features

Continuous and single measuring method
Direct and burst mode working modes
The two methods can be used together for calibration; the basic method can be used to modify the system error.
Could store up to 500 observed value
The delete function can delete unwanted measurement or all the storage before it starts a new measurement
Parameters can be set, and the alarm will sound when it passes beyond or bellow the parameters.
Print out function is available. Low supply indicator.
Manual shutdown and automatic shutdown mode

Technical Specifications

Measuring range	0~1250 µm
Lower limit of resolution(µm)	0.1ｕm（0-100），1ｕm（100-1250）
Calibration	Manufacturer for the calibration, zero calibration, the calibration foil calibration
One-point calibration(µm)	±(3%H+1) to ±(3%H+1) ±(3%H+1.5)
Two-point calibration(µm)	±[(1~3%H) +1] to ±[(1~3%H) +1] ±[(1~3%H) +1.5]
Minimum radius of curvature(µm)	Convexity 1.5mm (0.06in), Camber concave 3mm(0.12in)
Critical thickness of substrate(mm)	0.3mm to 0.5mm (0.01 – 0.02in)
Diameter of the minimum value(mm)	Φ5 – Φ7
Temperature	0℃-40℃ (32°F -104°F)
Humidity	20%RH-90%RH
Overall Dimension	147×65×30 (5.8 x 2.5x 1.1 in)
