Portable Leeb Hardness Tester – Acoustic Testing Pro
Acoustic Testing Pro Portable Leeb Hardness Tester delivers rapid, non‑destructive Leeb method hardness testing across multiple scales (HL, HB, HRB, HRC, HV, HS) with a measuring range of 170–960 HLD (17.9–69.5 HRC).
Overview
Acoustic Testing Pro Portable Leeb Hardness Tester delivers rapid, non‑destructive Leeb method hardness testing across multiple scales (HL, HB, HRB, HRC, HV, HS) with a measuring range of 170–960 HLD (17.9–69.5 HRC). This device features 360° measurement capability, ±6 HLD accuracy (at ~760 HLD), and supports OEM/ODM customization. It offers reliability and portability, backed by a 1‑year warranty and built‑in printer compatibility.
Features
- Supports Leeb hardness scales: HL, HB, HRB, HRC, HV, HS
- Measures in the range of 170–960 HLD (17.9–69.5 HRC)
- 360° measuring direction with ±6 HLD repeatability (~760 HLD)
- OEM/ODM/OBM customization and 1‑year warranty included
Technical Specifications
| Measuring Range | 170 to 960 HLD (17.9 to 69.5 HRC) |
| Supported Scales | HL, HB, HRB, HRC, HV, HS |
| Measurement Direction | 360° |
| Accuracy Tolerance | ±6 HLD (at 760 HLD) |
| Repeatability | 6 HLD (at 760 HLD) |
| Printer Paper Width | 1.75 in ± 0.02 in (44.5 mm ± 0.5 mm) |
| Printer Diameter | 1.57 in (40 mm) |
| Dimensions | 9.25 in x 3.54 in x 1.85 in (235 mm x 90 mm x 47 mm) |
| Weight | 1.36 lb (615 g) |
