Portable Infrared Blackbody Temperature Calibrator 50°C to 500°C – Acoustic Testing Pro
Infrared blackbody temperature calibrator with 50°C–500°C range, ±0.5°C accuracy, 2.25″ target, and 0.95 emissivity for precise industrial calibration.
Overview
GAO Tek portable infrared blackbody temperature calibrator is designed for accurate non-contact temperature calibration. It provides a wide temperature range of 50°C to 500°C with excellent stability and emissivity. The large 2.25″ target ensures reliable readings for infrared thermometers and thermal cameras. Compact, efficient, and precise, it is ideal for laboratories, industrial facilities, and field calibration use.
Features
- Wide temperature range from 50°C to 500°C (122°F to 932°F)
- High accuracy ±0.5°C at 100°C for precise calibration
- Stable performance with ±0.1°C stability at 100°C
- Large 2.25″ (57 mm) blackbody target with 0.95 emissivity
- Compact design with fast heating and cooling cycles
- Dual voltage operation: 230V AC or 110V AC
- Resolution up to 0.1°C/°F for fine measurement control
- Ideal for calibration of infrared thermometers and cameras
Technical Specifications
| Specification | Details |
| Calibration Type | Infrared Blackbody Temperature Calibrator |
| Temperature Range | 50°C to 500°C / 122°F to 932°F |
| Accuracy at 100°C | ±0.5°C / ±1.0°F |
| Accuracy at 500°C | ±1.8°C / ±3.6°F |
| Stability at 100°C | ±0.1°C / ±0.2°F |
| Stability at 500°C | ±0.3°C / ±0.6°F |
| Target Size | 2.25″ (57 mm) |
| Target Emissivity | 0.95 |
| Resolution | 0.1°C / °F |
| Heating Time | 40 minutes to maximum |
| Cooling Time | 45 minutes to 100°C |
| Power Supply | 230 VAC (±10%), 1.5A or 110V AC, 3A |
| Structure Material | Metal |
| Control Type | Digital Control |
| Application | Infrared Thermometer and Camera Calibration |
| Portability | Compact and Lightweight |
| Operating Principle | Blackbody Radiation Target |
| Packaging Size | 30 × 20 × 20 cm |
| Gross Weight | 3.4 kg |
| Safety Features | Overheat Protection |
| Temperature Range | 50°C to 500°C / 122°F to 932°F |
| Weight | 3.4 kg |
