Moisture Meter for Paper (High Precision/JIS P8127)
Acoustic Testing Pro Moisture Meter for Paper measures moisture in all kind of paper with high precision, and supports JIS P8127 standard for moisture content.
Overview
Acoustic Testing Pro Moisture Meter for Paper measures moisture in all kind of paper with high precision, and supports JIS P8127 standard for moisture content.
Key Features
- Have three different head types (K-300 series)
- Have optional accessories
- Measured by electrical impedance
- Used to measure water content in all kinds of paper
Technical Specifications
| Measurement methods | Electrical impedance type |
| Measurement standard | JIS P8127 (Photocopy paper, cardboard) |
| Measurement range (HK-300-1) | Photocopy paper: 4-15%,
Cardboard: 6-20%. |
| Measurement range (HK-300-2) | Photocopy paper: 4-25%,
Corrugated paper: 6-23%, Kraft paper: 5-24% |
| Measurement range (HK-300-3) | Photocopy paper: 2~10%,
Corrugated paper: 5~15%, Kraft paper: 2~10% |
| Measurement accuracy | Standard error of 0.4% (water content below 15%) |
| Volume (WxDxH) | 4.3×8.2×2.0 in (110x210x50 mm) |
| Power | 1.5Vx6 (approx. 0.45W) |
| Weight | 1.1 lbs. (0.5 kg) |
| Display mode | Minimum read value of LCD is 0.1% |
| Optical accessories | Special printer VZ-330Printer transmission line VZC-26 |
