Dew Point Meter with High Precision (Large Storage)
Acoustic Testing Pro Dew Point Meter with High Precision uses an advanced humidity sensor which provides high precision and quick detection, offers large storage.
Overview
Acoustic Testing Pro Dew Point Meter with High Precision uses an advanced humidity sensor which provides high precision and quick detection, offers large storage.
Key Features
- Automatic conversion to the standard value of 20 ℃
- Automatic calibration to zero
- Curve tracing and correction in the whole course
- Unique big screen display
- Unique ultra-large storage function
- Initiated curve display
- Initiated capacity display
- Advanced probe protection function
- Easy to operate and carry
- Pollution and disturbing resistant
- Good repeatability and quick response
- High sensitivity and good stability
Technical Specifications
| Detect scope | -112F – 68F (-80 ℃ ～+ 20 ℃) |
| Precision | ± 0.5 ℃ |
| Distinguishablity | 0.01 ℃or 0.1PPM |
| Respond time | when the dew point reaches to -31F-140F ( -35 ℃～-60 ℃), it is ≤4 min |
| Unit | dew point ℃, PPMV, temperature, pressure, and flow are displayed in the same screen |
| Working source | AC&DC, Li-ion battery can work for 8 hours continuously with over charge protection |
| Operation environment | Temperature -40F -140F ( -40 ℃～ + 60 ℃) pressure ≤1.5 Mpa |
| Output connector | RS232 or 4 ～ 20mA current (dew point output) |
| Size& weight | size 13.39in x 9.45in x 5.12in
( 340×240×130mm ) Weight 7.94lbs ( 3.6kg) |
| Air inflow port | self seal and quick plug |
| Air inflow channel | 5 m Ф4 4 Fluorine tube |
