Acoustic Testing Pro Voltage Signal Multifunction Calibrator

Overview

Acoustic Testing Pro voltage signal multifunction calibrator is a time-saving solution and generates high-quality results. It comes with HART communication function and supports one selected group of HART general instructions and general application instructions. It is a cost effective and compact loop calibrator, and a powerful HART communication tool.

Features

• State-of-the-art readout accuracy of 0.01%
• V, mA output, V, mA measurement
• mA simulation, mA measurement
• 24 V loop power supply
• 2.8 in TFT color screen, intuitive user interface
• Quick setting knob, easy to use
• Built-in optional resistance of 250 Ω for HART communication
• 1 μA current resolution
• 1 mV voltage resolution
• Source DC voltage to test input devices
• That can receive 0 V to 5 V, 1 V to 5 V or 0 V to 10 V signals
• AII measurement outputs adopt simple two-wire connection
• Auto shutdown function to extend battery life
• Adjustable step and ramp time
• Adjustable span selection (0 mA to 20 mA or 4 mA to 20 mA)
• Electronic valve test
• 4 mA to 20 mA current clamp measurement function
• HART communication function

Technical Specifications
