Acoustic Testing Pro Signal Professional Thermocouple Temperature

Name: Acoustic Testing Pro Signal Professional Thermocouple Temperature - Acoustic Testing Pro
SKU: ACTPTTPC-105

This Signal Professional Thermocouple Temperature has 24 V DC power supply, 0% to 90% relative humidity, and 14 °F to 131 °F operating temperature.

SKU: ACTPTTPC-105 Category: Temperature & Process Calibrators

Technical Specifications

DC V	Range 0 V to 60.000 V (Upper Display ±30 V) Accuracy 0.02%+2 0.05%+2
DC mA	Range 0 mA to 24 mA (Upper Display ±24 mV) Accuracy 0.02%+2 0.05%+2
DC mV	Range 0 mV to 15 mV to 80 mV 80 mV to 125 mV Accuracy 0.02%+2 0.05%+2
Resistance (2 Wires, 3 Wires)	Range 0 Ω to 440 Ω 400 Ω to 3200 Ω Accuracy 0.15 Ω 1.0 Ω 0.25 Ω 1.5 Ω
Resistance (4 Wires)	Range 0 Ω to 440 Ω 400 Ω to 3200 Ω Accuracy 0.1 Ω 0.5 Ω 0.15 Ω 1.0 Ω
Frequency	Range 1 Hz to 99.99 Hz 1000 Hz to 9999.99 Hz 10 kHz to 99.99 kHz Accuracy 0.01%+1 0.02%+1
RTD	Pt100, Pt1000, Cu50, Cu100
Power Supply	24 V DC
Operating Temperature	14 °F to 131 °F ( -10 °C to 55 °C)
Storage Temperature	-4 °F to 140 °F ( -20 ℃ to 60 ℃)
Relative Humidity	0% to 90%
Dimension	7.78 in x 3.77 in x 1.85 in (200 mm x 96 mm x 47 mm)
Weight	1.43 lb (650 g)
