Acoustic Testing Pro Quality COD Sensor
This Quality cod sensor has power supply of DC 12 V to 30 V, electrode cable of default 16.40 ft (5m) customizable and response time of ≤ 20 sec.
Features
- Measures Chemical Oxygen Demand (COD)
- Wi-Fi or 4G Connectivity
- Remote Transmission
- Automatic Cleaning
- Data Logging
Technical Specifications
| Power Supply | DC 12 V to 30 V |
| Consumption | 0.6 W to 1.8 W |
| Communication | RS 485 MODBUS to RTU or Baud Rate is 4800 |
| Measuring Range | COD, 0 mg to 500 mg per L equiv KHP, 0.1 mg per L |
| Response Time | ≤ 20 sec |
| Waterproof Class | IP 68 |
| Flow Velocity | < 3 m per s |
| Pressure Resistance | < 0.1 MPa |
| Maintenance Calibration Frequency | 3 months |
| Repeatability | ± 1% FS equiv KHP 77 °F (25 ℃） |
| Temp. Resolution | 32.18 °F (0.1 ℃) |
| Temp. Error | 32.9 °F (± 0.5 ℃) |
| Work Condition | 32 °F to 104 °F (0 ℃ to 40 ℃) |
| Electrode Cable | default 16.40 ft (5m) customizable |
