Acoustic Testing Pro Portable Thickness Gauge Meter
Acoustic Testing Pro Portable Thickness Gauge Meter adopts the magnetic and eddy current principle to measure in a non-destructive way .
Overview
Acoustic Testing Pro Portable Thickness Gauge Meter adopts the magnetic and eddy current principle to measure in a non-destructive way .The instrument is a portable thickness-measuring meter, it can measure the thickness of coating and plating rapidly, non-destructively and precisely.It can be used both in lab and the work site.This instrument can be widely used in the inspection fields, e.g. manufacturing, metal processing, chemical industry and commodity inspection, etc.It is a gauge essential for the material protection.
Technical Specifications
| Measuring Principle | Magnetic method |
| Measuring Range | (0 mm to 400 mm) 0 in to 15.7 in |
| Min Resolution | (0.1 mm) 0.0004 in |
| Tolerance One-Point Calibration | ± (3% H + 0.7) |
| Tolerance Two-Point Calibration | ± (1% H + 0.7) |
| Minimum Radius of Curvature (Convex) | (1 mm) 0.03 in |
| Minimum Measuring Area | F3 |
| Minimum Thickness of Base Material | (0.2 mm) 0.0007 in |
