Acoustic Testing Pro Oxygen Gas Analyzer
Acoustic Testing Pro Oxygen Gas Analyzer automatic recognition and prevention of the concentration calibration mis-operation, which is possible to avoid the poor performance that may be caused by human factors.
Overview
Acoustic Testing Pro Oxygen Gas Analyzer automatic recognition and prevention of the concentration calibration mis-operation, which is possible to avoid the poor performance that may be caused by human factors. Zero-point automatic tracking; long-term use will not be affected by the zero drift. Multi-level calibration for target points can ensure the linearity and accuracy of the measurements.
Technical Specifications
| Measuring Range | O2: 0% Vol to 30% Vol |
| Resolution | 0.01% Vol |
| Sensor Type | Infrared Sensor |
| Measuring Type | Built-in Pump Suction |
| Response Time (T90) | <30 s |
| Display | 2.31 in (58.6 mm) High-Definition Color Screen |
| Alarm Method | Sound & Light Alarm Vibration Alarm Sound & Light + Vibration Alarm Turning Off the Alarm |
| Battery | DC 3.7 V, 4500 mAh High-Capacity Rechargeable Polymer Battery |
| Data Storage | Standard Capacity is 100,000 Entries |
| Working Temperature | 104 °F to 158 °F (40 °C to +70 °C) |
| Working Humidity | ≤10% RH to 95% RH |
| Ex Grade | Ex ia IIC T6 Ga Intrinsically Safe Type |
| Ingress Protection | IP 65 |
| Weight | 0.661 lb. (300 g) |
| Dimension | 6.3 in x 2.7 in x 1.1 in (160 mm × 70 mm × 28 mm) |
