Acoustic Testing Pro Multifunction Loop Process Calibrator
Acoustic Testing Pro multifunction loop process calibrator combines with temperature process calibrator and loop process calibrator function.
Overview
Acoustic Testing Pro multifunction loop process calibrator combines with temperature process calibrator and loop process calibrator function. Is easily measure and source most of the process parameters mA, volts, temperature, frequency, ohms in one tool.
Technical Specifications
| DC Voltage | 1000 mV to 10 V |
| DC Current | 20 mA |
| Resistance | 4000 Ω to 40 kΩ |
| Frequency | 2000 Hz to 100 kHz |
| Pulses | 100 Hz to 1 kHz |
| Power | 1.2V x 6 AA |
| Operation Temperature | 14 °F to 131 °F (-10 °C to 55 °C) |
| Product Size | 7.67 in x 3.74 in x 2.28 in (195 mm x 95 mm x 58 mm) |
| Product net weight | 1.43 lb (650 g) |
