Acoustic Testing Pro Monitoring Sensor Controller
Acoustic Testing Pro monitoring sensor controller is an intelligent on-line water quality analysis instrument.
Overview
Acoustic Testing Pro monitoring sensor controller is an intelligent on-line water quality analysis instrument. It can continuously monitor water turbidity. Wildly used for urban sewage treatment plants, chemical industry, printing and dyeing, paper, pharmaceutical, electroplating and environmental protection fields.
Technical Specifications
| Power supply | 12 vdc to 24 vdc |
| Measurement range | 0 ntu to 100 ntu or 0 ntu to 1000 ntu or 0 ntu to 4000 ntu |
| Measurement accuracy | ± 5 % or ± 3 ntu |
| Resolution | 0.1 ntu |
| Output signal | RS485 or 4 mA to 20 mA |
| Response time T90 | ＜90 s |
| Responding speed | ≤ 15 s |
| Power consumption | ≤ 15 w (12 vdc, 77 °F) (25 ℃) |
| Working temperature | 32 °F to 122 °F (0 ℃ to 50 ℃) |
| Temperature compensation | -4 °F to 176 °F (-20 °C to 80 °C) |
