Acoustic Testing Pro Industrial High Temperature Data Logger
This Industrial High Temperature Data Logger has detector resolution of 256 pixel, thermal sensitivity of 60 mK and frame rate of 25 Hz.
Technical Specifications
| Detector Type | Uncooed vanadium oxide VOx Focal plane |
| Detector Resolution | 256 pixel x 192 pixel |
| Thermal Sensitivity | ＜60 mK |
| Frame Rate | 25 Hz |
| Fov | 42° x 32.1° |
| Focusing | Focus |
| Color Palette | at least 6 color palettes |
| Visible Light Resolution | 1920 pixel x 1080 pixel |
| Light Supplementary | Built in LED light |
| Alarm Function | All temperature measurement points, areas temperature and average temperature can configure separately alarm output |
| Protocol Or Standard | ONVIF, GB 28181, MODBUS |
| Mobile Format | MJPEG or H.264 |
| Manual Or Automatic Adjust | Support |
| Storage Medium | Built in saver or TF card maximum memory 64 G |
| Picture Storage Mode | Infrared or visible light separate or simultaneous or Fusion |
| File Format | JPEG, MP 4 |
| B Or S Configuring Interface | Available |
| C Or S Configuring Interface | Available |
| Sdk | Output externally origin temperature data , Support SDK for user secondary development |
| Power Supply | DC 12 V |
| Video Interface | Analog video |
| Network Interface | including 10 M or 100 M adaptive ethernet port and POE power supply |
| Alarm Interface | Alarm I or O interface |
| Resolution | 1920 pixel x 1080 pixel |
| Visible Light Fusion | Dual wave image fusion enhance |
| Accuracy | ±35.6 ℉ (±2 ℃) or reading 2% |
| Point Or Line Or Area | 6 removable points, 1 line, 6 removable areas |
| Preset | Available |
| Protection Level | IP 67 |
| Humidity | ≤95% No condensation |
| Range | -4 ℉ to 248 ℉ (-20 ℃ to 120 ℃) , wide dynamic -4 to 752 ℉ (-20 ℃ to 400 ℃) |
| Working Temperature | -4 ℉ to 140 ℉ (-20 ℃ to 60 ℃ ) |
| Storage Temperature | -40 ℉ to 158 ℉ (-40 ℃ to 70 ℃) |
| Dimension | 2.13 in x 0.98 in x 3.11 in (54 mm x 25 mm x 79 mm) |
