Acoustic Testing Pro Ground Lead Conductivity Tester

Name: Acoustic Testing Pro Ground Lead Conductivity Tester - Acoustic Testing Pro
SKU: ACTPCT-188

This Ground Lead Conductivity Tester has a measuring range of 39.37 in Ω to 78700.78 in Ω, relative humidity of ≤80%, and power AC 220 V±10%,50 Hz.

SKU: ACTPCT-188 Category: Conductivity Instruments

Technical Specification

Measuring range	39.37 in Ω to 78700.78 in Ω (1000 mm Ω to 1999000 mm Ω)
Resolution	39.37 in Ω (1000 mm Ω)
Test current	DC 1 A,2 A,5 A, 10 A four fixed current gears
Measurement accuracy	±(0.5%+2d)
Measuring radius	1968.50 in (50 cm)
Display mode	Three-half LCD display
Working mode	continuous
Working power supply	AC 220V ±10%, 50 Hz
Working Environment	Temperature: 50 ^oF to 104 ^oF (10 °C to 40 °C)
Relative humidity	Humidity: ≤80% RH≤80%
volume	11.81 in x 10.62 in x 7.87 in (300 mm x 270 mm x 200 mm)
weight	11.02 lb (5 kg) (without accessories)
