Acoustic Testing Pro Crack Detector
Acoustic Testing Pro Crack Detector is Used to test crack depth and sound wave velocity in concrete according to sound wave diffraction propagation principle.
Overview
Acoustic Testing Pro Crack Detector is Used to test crack depth and sound wave velocity in concrete according to sound wave diffraction propagation principle. It is an intelligent instrument with combined functions such as testing, saving and transiting data.
Features
- Large-screen display: 5 “color LCD display with a resolution of 640 x 480;
- Can test larger crack depth, it can be up to 650mm
- The tester is equipped with a dedicated scale, portable and practical, can improve the test efficiency.
- Easy data transfer: the instrument can be directly connected to the computer, no need U disk.
- Powerful professional windows data analysis processing software: data can be imported into Word and Excel, convenient and user-friendly post-processing of data.
Technical Specifications
| Crack Depth Test Range | =< 25.6 in (650 mm) |
| Crack Depth Accuracy | =< 10% |
| Data Storage Capacity | Can store more than 6000 cracks measured point data and image |
| Screen | 640 x 480 resolution |
| Power | 6 pcs No. 5 battery |
| Operating Temperature | -34 °F to +122 °F (-10 °C to +50 °C) |
| Main Host Dimension | 8.19 in x 6.61 in x 3.35 in (208mm x 168mm x 85mm) |
