Name: Acoustic Testing Pro Conductivity Tester For Laboratory - Acoustic Testing Pro
SKU: ACTPCT-161

Features

High-resolution 7-inch (177 mm) capacitive touch screen
Built-in microprocessor with intelligent features: auto-calibration, ATC, data storage, clock display
USB output, wireless printing, self-diagnosis
Smart electrode status display for accuracy
Stores 1000 test data sets, easily exportable to Excel via USB
Advanced conductivity measurement technology, K=1 electrode for 0.5 μS/cm to 200 mS/cm range
Switch between conductivity, TDS, salinity, and resistivity
Multinomial calculation for precise TDS and salinity conversion
Auto-recognizes 8 conductivity standard solutions, Europe & USA or China options

Technical specifications

Cond.	Measuring range	Conductivity:
		0.00 μS/cm to 20.00 μS/cm, 20.0 μS/cm to 200.0 μS/cm
		200 μS/cm to 2000 μS/cm, 2.00 mS/cm to 20.00 mS/cm
		(20.0 mS/cm to 200.0 mS/cm
		(200 mS/cm to 2000 mS/cm (K=10)
		TDS: 0 g/L to 100 g/L
		Salinity:0 ppt to 100 ppt
		Resistivity:(0 to 100) MΩ·cm
	Resolution	0.01/0.1/1 μS/cm; 0.01/0.1 mS/cm
	Accuracy	Electrode: ±0.5% FS,Meter: ±0.8% FS
	Temp. compensation range	32 °F to 122 °F (0 ℃ to 50 ℃), auto
	Electrode constant	0.1/0.5/1/5/10/50/100 cm 1
	Reference Temp.	77 °F (25 ℃),68 °F (20 ℃),64.4 °F (18 ℃)
Temp.	Range	14 °F to 230 °F (-10 ℃ to 110 ℃)
	Resolution	32.18 °F (0.1 ℃)
	Accuracy	41°F to 140°F (5 ℃ to 60 ℃) Others: ±1.44 °F (±0.8 ℃)
Other	Display	7-inch (177 mm) colored capacitive touch screen
	Data storage	1000 sets
	Power	12 V/1 A
	Output	USB
	Ambient Temp.	59 °F to 86 °F (15 ℃ to 30 ℃)
	Ambient Humidity	≤85%
	IP grade	IP 54
Meter Kits	Electrode holder
	Cond electrode (K=1)
	Temperature probe.
	Power adapter
	manual
Dimensions	8.46 in x 6.69 in x 1.46 in (215 mm × 170 mm ×37 mm) Weight: 1.32 lb (600 g)
