Acoustic Testing Pro coating Thickness Gauges Meter
Acoustic Testing Pro coating Thickness Gauges Meter is using Magnetic and Eddy thickness measurement.
Overview
Acoustic Testing Pro coating Thickness Gauges Meter is using Magnetic and Eddy thickness measurement.It can measure the thickness of non-magnetic coating layers on magnetic substrate. Such as: (aluminum, chrome, copper, enamel, rubber, paint) on magnetic substrate(steel, iron, alloy and magnetic stainless steel).The gauge have data storage, the USB interface, it can save 1173 measuring-records, each record contains the information of measuring-results and measuring-time, it’s very useful for you to control the quality of your products.
Technical Specifications
| Measuring Principle | Fe , NFe |
| Measuring Range (pm) | 0 µm to 1500 µm |
| Minimum Resolution (pm) | O.l pm |
| Min Curvature of The Min Area (mm) | Convex: (5 mm) , concave: (25 mm) ( 0,9843 in) |
| Diameter of The Min Area | 7 |
| Critical Thickness of Substrate (mm) | (0.5 mm) 0.020 in |
| Memory | 1173 |
| Dimensions | (100 mm x 65 mm x 25 mm) 3.94 in x 2.56 in x 0.98 in |
| Power Supply | AAA Alkaline battery |
| Standard Configuration | Main Machine,4 calibration specimens (38 pm > 126 _m,183 pm, 249 pm) |
| Accuracy | ±‹1-3% H+1›µm H refers to the thickness of testing piece |
