Overview

Acoustic Testing Pro Benchtop Potassium Ion Meter professional benchtop potassium ion meter, suitable for laboratory applications, accuracy: 1% F.S.

Features

Large backlit LCD display
2-5 points calibration, 8 concentration points
Direct ion concentration readout
Selectable concentration units – ppm, mg/L, mol/L
Automatic temperature compensation
Auto-read function locks measurement endpoint
Calibration due alarm
Automatic electrode diagnosis
Setup menu for calibration points, ionic valency, stability criteria, temperature unit, auto-power off
Reset function resumes factory settings
Expanded memory stores/recalls up to 500 data sets
USB communication interface for data transfer

Ion Concentration Range	0.04 ppm to 39000 ppm
Ion Concentration Resolution	0.001, 0.01, 0.1, 1, automatic
Ion Concentration Accuracy	±1% F.S.
Ion Concentration Calibration	2 to 5 points
Ion Concentration Calibration Solutions	0.001 / 0.01 / 0.1 / 1 / 10 / 100 / 1000 / 10000
Ion Concentration Measurement Units	ppm, mg/L, mol/L, mmol/L
MV Range	-1999.9 to 1999.9 mv
MV Resolution	0.1 mv
MV Accuracy	±0.2 mv
Temperature Range	0 to 105 °C / (32 °F to 221 °F)
Temperature Resolution	0.18 °F (0.1 °C)
Temperature Accuracy	±0.9 °F (±0.5 °C)
Temperature Calibration	1 point
Temperature Calibration Range	Reading ±50 °F (±10°C)
Temperature Compensation	32 °F to 212 °F (0 to 100° C), manual or automatic
Hold Function	Manual / Auto-read measurement endpoint
Stability Criteria	Low / High
Calibration Due Alarm	1 to 31 days or off
Memory	Stores up to 500 data sets
Output	USB communication interface
Connector	BNC, 0.13 in (3.5 mm) jack socket
Display	Custom LCD 4.92 in x 3.93 in (125 mm × 100 mm)
Power Supply	5 V DC power adapter
Environmental Conditions	32 °F to 122 °F (0 °C to 50 °C), relative humidity < 80%
Dimensions	8.26 in x 7.40 in x 2.32 in (210 mm × 188 mm × 60 mm)
Weight	3.30 lbs. (1.5 kg)
