Acoustic Testing Pro Benchtop Fluoride Ion Meter With Auto-Hold Functionality
This Benchtop Fluoride Ion Meter has an ion concentration range of 0.02 ppm to 1900 ppm, mV resolution of 0.1 mV, and accuracy mV of ±0.2 mV.
Features
- Backlit LCD for precision reading
- 2-5 points calibration, 8 concentration
- Direct ion readout for simplicity
- Selectable units – ppm, mg/L, mol/L
- Accurate readings with temp compensation
- Auto-Read function locks measurement endpoint
- Calibration due alarm for regular calibration
- Auto electrode diagnosis with calibration info
- Setup menu for customizable settings
- Reset to factory defaults feature
- Memory for 500 data sets
- USB for easy data transfer to PC
Technical Specifications
| Ion Concentration Range | 0.02 ppm to 1900 ppm |
| Ion Concentration Resolution | 0.001, 0.01, 0.1, 1, automatic |
| Ion Concentration Accuracy | ±0.5% F.S. |
| Ion Concentration Calibration Points | 2 to 5 points |
| Ion Concentration Calibration Solutions | 0.001 / 0.01 / 0.1 / 1 / 10 / 100 / 1000 / 10000 |
| Ion Concentration Measurement Units | ppm, mg / L, mol / L, mmol / L |
| MV Range | -1999.9 mV to 1999.9 mV |
| MV Resolution | 0.1 mV |
| MV Accuracy | ±0.2 mV |
| Temperature Range | 32 °F to 221 °F (0 °C to 105 °C) |
| Temperature Resolution | 32.18 °F (0.1°C) |
| Temperature Accuracy | ±0.9 °F (±0.5 °C) |
| Temperature Offset Calibration | 1 point |
| Temperature Calibration Range | Reading ±18 °F / ±10°C |
| Hold Function | Manual / Auto-read measurement endpoint |
| Stability Criteria | Low / High |
| Calibration Due Alarm | 1 to 31 days or off |
| Memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | BNC, 0.13 in (3.5 mm) jack socket |
| Display | Custom LCD 4.92 in × 3.93 in (125 mm × 100 mm) |
| Power Supply | 5 V DC power adapter |
| Environmental Conditions | 32 °F to 122 °F (0 °C to 50°C), relative humidity <80% |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100 °C), manual or automatic |
| Dimensions | 8.26 in × 7.40 in × 2.36 in (210 mm x 188 mm x 60 mm) |
| Weight | 3.30 lb (1.5 kg) |
