Acoustic Testing Pro Benchtop Calcium Ion Meter
This Benchtop Calcium Ion Meter has an accuracy of ±0.2 mV, resolutions of 0.1 mV, and working temperature range of 32 °F to 221 °F.
Features
- Professional calcium ion meter with large backlit LCD display
- 2-5 points calibration, 8 concentration points selection
- Direct ion concentration readout for simplified measurements
- Selectable units – ppm, mg/L, mol/L
- Automatic temperature compensation for accuracy
- Auto-read function locks measurement endpoint
- Calibration due alarm for regular maintenance
- Automatic electrode diagnosis displays calibration points and slopes
- Setup menu customizes calibration, ionic valency, stability criteria, etc
- Reset function restores factory defaults
- Expanded memory stores/recalls up to 500 data sets
- USB interface for data transfer and timed interval readings
Technical Specification
| Range | -1999.9 mV to 1999.9 mV |
| Resolution | 0.1 mV |
| Accuracy | ±0.2 mV |
| Hold Function | Manual or Auto-read measurement endpoint |
| Stability Criteria | Low or High |
| Calibration Due Alarm | 1 day to 31 days or off |
| Memory | Stores up to 500 data sets |
| Output | USB communication interface |
| Connector | BNC, 0.14 in (3.5 mm) jack socket |
| Display | Custom LCD 4.92 in × 3.94 in (125 mm × 100 mm) |
| Power Supply | 5 V DC power adapter |
| Environmental Conditions | 32 °F to 122 °F (0 °C to 50 °C), relative humidity < 80% |
| Temperature Range | 32 °F to 221 °F (0 °C to 105°C) |
| Temperature Resolution | 32.18 °F. (0.1°C) |
| Temperature Accuracy | ±0.9 °F (±0.5°C) |
| Temperature Calibration | 1 point |
| Temperature Calibration Range | Reading 14 °F to 50 °F (±10 °C) |
| Temperature Compensation | 32 °F to 212 °F (0 °C to 100 °C), manual or automatic |
| Dimensions | 8.27 in × 7.40 in × 2.36 in (210 mm × 188 mm × 60 mm) |
| Weight | 3.31 lb. (1.5 kg) |
